Direct Digital Synthesis (DDS)
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Series | Package/Case | Packaging | Product Status | Resolution (Bits) | Master fclk | Tuning Word Width (Bits) | Voltage - Supply | Operating Temperature | Grade | Qualification | Mounting Type | Supplier Device Package |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
DDS39RFS10ACK16-BIT, 1-CHANNEL, 20.48GSPS 12G |
2,566 |
|
- |
- | 256-BBGA, FCBGA | Tube | Active | 16 b | 10.24 GHz | - | 0.95V ~ 1.05V, 1.71V ~ 1.89V | -40°C ~ 85°C | - | - | Surface Mount | 256-FCBGA (17x17) |
|
|
DDS39RFS12ACK16-BIT, 1-CHANNEL, 24GSPS 12GHZ |
3,518 |
|
- |
- | 256-BBGA, FCBGA | Tube | Active | 16 b | 12 GHz | - | 0.95V ~ 1.05V, 1.71V ~ 1.89V | -40°C ~ 85°C | - | - | Surface Mount | 256-FCBGA (17x17) |
|
|
DDS39RF10ACK16-BIT, 2-CHANNEL, 20.48GSPS, 12 |
4,890 |
|
- |
- | 256-BBGA, FCBGA | Tube | Active | 16 b | 10.24 GHz | - | 0.95V ~ 1.05V, 1.71V ~ 1.89V | -40°C ~ 85°C | - | - | Surface Mount | 256-FCBGA (17x17) |
|
|
DDS39RFS10ACL16-BIT, 1-CHANNEL, 20.48GSPS 12G |
4,897 |
|
- |
- | 256-BBGA, FCBGA | Tube | Active | 16 b | 10.24 GHz | - | 0.95V ~ 1.05V, 1.71V ~ 1.89V | -40°C ~ 85°C | - | - | Surface Mount | 256-FCBGA (17x17) |
|
|
DDS39RF12ACK16-BIT, 2-CHANNEL, 24GSPS 12GHZ |
4,816 |
|
- |
- | 256-BBGA, FCBGA | Tube | Active | 16 b | 12 GHz | - | 0.95V ~ 1.05V, 1.71V ~ 1.89V | -40°C ~ 85°C | - | - | Surface Mount | 256-FCBGA (17x17) |
|
|
DDS39RFS12ACL16-BIT, 1-CHANNEL, 24GSPS 12GHZ |
4,391 |
|
- |
- | 256-BBGA, FCBGA | Tube | Active | 16 b | 12 GHz | - | 0.95V ~ 1.05V, 1.71V ~ 1.89V | -40°C ~ 85°C | - | - | Surface Mount | 256-FCBGA (17x17) |
|
|
DDS39RF10ACL16-BIT, 2-CHANNEL, 20.48GSPS, 12 |
2,507 |
|
- |
- | 256-BBGA, FCBGA | Tube | Active | 16 b | 10.24 GHz | - | 0.95V ~ 1.05V, 1.71V ~ 1.89V | -40°C ~ 85°C | - | - | Surface Mount | 256-FCBGA (17x17) |
|
|
DDS39RF12ACL16-BIT, 2-CHANNEL, 24GSPS 12GHZ |
3,294 |
|
- |
- | 256-BBGA, FCBGA | Tube | Active | 16 b | 12 GHz | - | 0.95V ~ 1.05V, 1.71V ~ 1.89V | -40°C ~ 85°C | - | - | Surface Mount | 256-FCBGA (17x17) |
|
AD9832BRU-REELIC DDS 25MHZ 10BIT 16TSSOP |
4,383 |
|
Datasheet |
- | 16-TSSOP (0.173", 4.40mm Width) | Tape & Reel (TR) | Obsolete | 10 b | 25 MHz | 32 b | 2.97V ~ 5.5V | -40°C ~ 85°C | - | - | Surface Mount | 16-TSSOP |
|
|
AD9832BRU-REEL7IC DDS 25MHZ 10BIT 16TSSOP |
3,032 |
|
Datasheet |
- | 16-TSSOP (0.173", 4.40mm Width) | Tape & Reel (TR) | Obsolete | 10 b | 25 MHz | 32 b | 2.97V ~ 5.5V | -40°C ~ 85°C | - | - | Surface Mount | 16-TSSOP |
|
|
AD9835BRU-REEL7IC DDS 50MHZ 10BIT 16TSSOP |
1,010 |
|
Datasheet |
- | 16-TSSOP (0.173", 4.40mm Width) | Tape & Reel (TR) | Obsolete | 10 b | 50 MHz | 32 b | 4.75V ~ 5.25V | -40°C ~ 85°C | - | - | Surface Mount | 16-TSSOP |
|
ISL5314INIC DDS 125MHZ 14BIT 48TQFP |
2,958 |
|
Datasheet |
- | 48-LQFP | Tray | Obsolete | 14 b | 125 MHz | 48 b | 3V ~ 5.5V, 4.5V ~ 5.5V | -40°C ~ 85°C | - | - | Surface Mount | 48-LQFP (7x7) |
|
|
ISL53570IQZR5267IC DDS 48TQFP |
2,758 |
|
- |
- | 48-LQFP | Tray | Obsolete | - | - | - | - | - | - | - | Surface Mount | 48-LQFP (7x7) |
