Power Transformers
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Series | Packaging | Product Status | Type | Voltage - Primary | Voltage - Secondary (Full Load) | Current - Output (Max) | Primary Winding(s) | Secondary Winding(s) | Center Tap | Power - Max | Mounting Type | Termination Style | Size / Dimension | Height - Seated (Max) | Voltage - Isolation | Weight |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
182M110PWR XFMR TOROIDAL 300VA CHAS MT Hammond Manufacturing |
4,429 |
|
Datasheet |
182 | Bulk | Active | Toroidal | 117V, 234V | Parallel 110V, Series 220V | Parallel 2.72A, Series 1.36A | Dual | Dual | No | 300VA | Chassis Mount | Wire Leads | - | 57.66mm | 4000Vrms | 5.6 lbs (2.5 kg) |
|
PWDP13090PWR XFMR LAMINATED CHAS MT Hammond Manufacturing |
1,747 |
|
Datasheet |
PWDAHL | Case | Active | Laminated Core | 115V | - | - | Dual | Dual | Yes | - | Chassis Mount | Wire Leads | - | 86.89mm | - | - |
|
|
PWDP13094PWR XFMR LAMINATED CHAS MT Hammond Manufacturing |
2,116 |
|
Datasheet |
PWDAHL | Case | Active | Laminated Core | 115V | - | - | Dual | Dual | Yes | - | Chassis Mount | Wire Leads | - | 85.73mm | - | - |
|
|
PWDI13117PWR XFMR Hammond Manufacturing |
4,339 |
|
Datasheet |
* | Case | Active | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
|
|
6K7VGPWR XFMR Hammond Manufacturing |
1,718 |
|
- |
- | Bulk | Active | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
|
|
265W5PWR XFMR 250VA CHAS MT Hammond Manufacturing |
2,804 |
|
Datasheet |
265 | Bulk | Active | - | 117V, 234V | 5V | 50A | Dual | Single | Yes | 250VA | Chassis Mount | Wire Leads | 114.30mm L x 95.25mm W | 95.25mm | 2000Vrms | - |
|
|
182S24PWR XFMR TOROIDAL 500VA CHAS MT Hammond Manufacturing |
2,898 |
|
Datasheet |
182 | Bulk | Obsolete | Toroidal | 117V, 234V | Parallel 24V, Series 48V | Parallel 20.84A, Series 10.42A | Dual | Dual | No | 500VA | Chassis Mount | Wire Leads | - | 56.13mm | 4000Vrms | 8.5 lbs (3.9 kg) |
|
|
265U10PWR XFMR 175VA CHAS MT Hammond Manufacturing |
2,825 |
|
Datasheet |
265 | Bulk | Active | - | 117V, 234V | 10V | 17.5A | Dual | Single | Yes | 175VA | Chassis Mount | Wire Leads | 104.78mm L x 92.08mm W | 87.33mm | 2000Vrms | - |
|
|
265X6PWR XFMR 158VA CHAS MT Hammond Manufacturing |
4,115 |
|
Datasheet |
265 | Bulk | Active | - | 117V, 234V | 6.3V | 25A | Dual | Single | Yes | 158VA | Chassis Mount | Wire Leads | 95.25mm L x 95.25mm W | 79.38mm | 2000Vrms | - |
|
715PWR XFMR LAMINATED 200VA CHAS MT Hammond Manufacturing |
2,605 |
|
Datasheet |
700 | Bulk | Active | Laminated Core | 115V | 1020V | 300mA | Single | Single | Yes | 200VA | Chassis Mount | Wire Leads | 95.25mm L x 117.60mm W | 114.30mm | - | 9 lbs (4.1 kg) |
