Power Transformers
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Series | Packaging | Product Status | Type | Voltage - Primary | Voltage - Secondary (Full Load) | Current - Output (Max) | Primary Winding(s) | Secondary Winding(s) | Center Tap | Power - Max | Mounting Type | Termination Style | Size / Dimension | Height - Seated (Max) | Voltage - Isolation | Weight |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
164E36PWR XFMR LAMINATED 2.4VA TH Hammond Manufacturing |
2,613 |
|
Datasheet |
164 | Bulk | Active | Laminated Core | 115V | Parallel 18V, Series 36V | Parallel 130mA, Series 65mA | Single | Dual | No | 2.4VA | Through Hole | PC Pin | 34.93mm L x 28.56mm W | 30.18mm | 2500Vrms | 0.25 lb (113.4 g) |
|
160G40PWR XFMR LAMINATED 10VA TH Hammond Manufacturing |
4,744 |
|
Datasheet |
160 | Bulk | Active | Laminated Core | 115V, 230V | Parallel 20V, Series 40V | Parallel 500mA, Series 250mA | Dual | Single, Multiple Taps | No | 10VA | Through Hole | PC Pin | 49.28mm L x 36.58mm W | 42.93mm | 2000Vrms | 0.54 lb (244.94 g) |
|
160D12PWR XFMR LAMINATED 1VA TH Hammond Manufacturing |
2,108 |
|
Datasheet |
160 | Bulk | Active | Laminated Core | 115V, 230V | Parallel 6.3V, Series 12.6V | Parallel 140mA, Series 70mA | Dual | Single, Multiple Taps | No | 1VA | Through Hole | PC Pin | 25.40mm L x 35.05mm W | 21.08mm | 2000Vrms | 0.13 lb (58.97 g) |
|
229E16PWR XFMR SEMI-TORO 2VA TH Hammond Manufacturing |
1,267 |
|
Datasheet |
229 | Bulk | Active | Semi-Toroidal | 115V, 230V | Parallel 8V, Series 16V | Parallel 300mA, Series 150mA | Dual | Dual | No | 2VA | Through Hole | PC Pin | 39.62mm L x 47.75mm W | 16.51mm | 1750Vrms | 0.35 lb (158.76 g) |
|
187B56PWR XFMR LAMINATED 6.16VA CHAS Hammond Manufacturing |
1,074 |
|
Datasheet |
187 | Box | Active | Laminated Core | 115V | 56V | 110mA | Single | Single | Yes | 6.16VA | Chassis Mount | Solder, Quick Connect | 60.20mm L x 41.28mm W | 34.80mm | 2000Vrms | 0.45 lb (204.12 g) |
|
186D28PWR XFMR LAMINATED 30VA CHAS MT Hammond Manufacturing |
2,786 |
|
Datasheet |
186 | Box | Active | Laminated Core | 115V, 230V | 28V | 1.07A | Dual | Single | Yes | 30VA | Chassis Mount | Solder, Quick Connect | 82.55mm L x 52.20mm W | 49.02mm | 2000Vrms | 1.3 lbs (589.7 g) |
|
|
229B120PWR XFMR SEMI-TORO 12VA TH Hammond Manufacturing |
3,003 |
|
Datasheet |
229 | Bulk | Active | Semi-Toroidal | 115V, 230V | Parallel 60V, Series 120V | Parallel 200mA, Series 100mA | Dual | Dual | No | 12VA | Through Hole | PC Pin | 50.80mm L x 63.50mm W | 27.18mm | 1750Vrms | 0.61 lb (276.69 g) |
|
183E10PWR XFMR LAMINATED 2.5VA TH Hammond Manufacturing |
4,556 |
|
Datasheet |
183 | Bulk | Active | Laminated Core | 115V, 230V | Parallel 5V, Series 10V | Parallel 500mA, Series 250mA | Dual | Dual | No | 2.5VA | Through Hole | PC Pin | 41.28mm L x 36.50mm W | 28.58mm | 4000Vrms | 0.17 lb (77.11 g) |
|
164F28PWR XFMR LAMINATED 6VA TH Hammond Manufacturing |
4,842 |
|
Datasheet |
164 | Bulk | Active | Laminated Core | 115V | Parallel 14V, Series 28V | Parallel 400mA, Series 200mA | Single | Dual | No | 6VA | Through Hole | PC Pin | 41.28mm L x 33.32mm W | 33.32mm | 2500Vrms | 0.44 lb (199.58 g) |
|
|
186C20PWR XFMR LAMINATED 12VA CHAS MT Hammond Manufacturing |
4,623 |
|
Datasheet |
186 | Box | Active | Laminated Core | 115V, 230V | 20V | 600mA | Dual | Single | Yes | 12VA | Chassis Mount | Solder, Quick Connect | 71.37mm L x 43.82mm W | 41.15mm | 2000Vrms | 0.69 lb (312.98 g) |
