Power Transformers
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Series | Packaging | Product Status | Type | Voltage - Primary | Voltage - Secondary (Full Load) | Current - Output (Max) | Primary Winding(s) | Secondary Winding(s) | Center Tap | Power - Max | Mounting Type | Termination Style | Size / Dimension | Height - Seated (Max) | Voltage - Isolation | Weight |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
183E28PWR XFMR LAMINATED 2.5VA TH Hammond Manufacturing |
3,348 |
|
Datasheet |
183 | Bulk | Active | Laminated Core | 115V, 230V | Parallel 14V, Series 28V | Parallel 180mA, Series 90mA | Dual | Dual | No | 2.5VA | Through Hole | PC Pin | 41.28mm L x 36.50mm W | 28.58mm | 4000Vrms | 0.17 lb (77.11 g) |
|
164D12PWR XFMR LAMINATED 1.1VA TH Hammond Manufacturing |
2,675 |
|
Datasheet |
164 | Bulk | Active | Laminated Core | 115V | Parallel 6.3V, Series 12.6V | Parallel 180mA, Series 90mA | Single | Dual | No | 1.1VA | Through Hole | PC Pin | 34.93mm L x 28.56mm W | 33.32mm | 2500Vrms | 0.17 lb (77.11 g) |
|
162G12PWR XFMR LAMINATED 12VA TH Hammond Manufacturing |
2,232 |
|
Datasheet |
162 | Bulk | Active | Laminated Core | 115V, 230V | Parallel 6.3V, Series 12.6V | Parallel 2A, Series 1A | Dual | Dual | No | 12VA | Through Hole | PC Pin | 47.63mm L x 39.67mm W | 38.10mm | 2500VDC | 0.7 lb (317.51 g) |
|
164F56PWR XFMR LAMINATED 6VA TH Hammond Manufacturing |
2,595 |
|
Datasheet |
164 | Bulk | Active | Laminated Core | 115V | Parallel 28V, Series 56V | Parallel 220mA, Series 110mA | Single | Dual | No | 6VA | Through Hole | PC Pin | 41.28mm L x 33.32mm W | 33.32mm | 2500Vrms | 0.44 lb (199.58 g) |
|
161F56PWR XFMR LAMINATED 4.4VA TH Hammond Manufacturing |
1,495 |
|
Datasheet |
161 | Bulk | Active | Laminated Core | 115V | Parallel 28V, Series 56V | Parallel 160mA, Series 80mA | Single | Single, Multiple Taps | No | 4.4VA | Through Hole | PC Pin | 42.93mm L x 31.75mm W | 36.83mm | 2000Vrms | 0.33 lb (149.69 g) |
|
|
183H16PWR XFMR LAMINATED 20VA TH Hammond Manufacturing |
3,881 |
|
Datasheet |
183 | Bulk | Active | Laminated Core | 115V, 230V | Parallel 8V, Series 16V | Parallel 2.5A, Series 1.25A | Dual | Dual | No | 20VA | Through Hole | PC Pin | 57.15mm L x 47.63mm W | 41.28mm | 4000Vrms | 0.9 lb (408.23 g) |
|
|
183H12PWR XFMR LAMINATED 20VA TH Hammond Manufacturing |
1,671 |
|
Datasheet |
183 | Bulk | Active | Laminated Core | 115V, 230V | Parallel 6.3V, Series 12.6V | Parallel 3.2A, Series 1.6A | Dual | Dual | No | 20VA | Through Hole | PC Pin | 57.15mm L x 47.63mm W | 41.28mm | 4000Vrms | 0.9 lb (408.23 g) |
|
164G10PWR XFMR LAMINATED 12VA TH Hammond Manufacturing |
2,461 |
|
Datasheet |
164 | Bulk | Active | Laminated Core | 115V | Parallel 5V, Series 10V | Parallel 2.4A, Series 1.2A | Single | Dual | No | 12VA | Through Hole | PC Pin | 47.63mm L x 39.67mm W | 38.10mm | 2500Vrms | 0.7 lb (317.51 g) |
|
162H16PWR XFMR LAMINATED 20VA TH Hammond Manufacturing |
3,198 |
|
Datasheet |
162 | Bulk | Active | Laminated Core | 115V, 230V | Parallel 8V, Series 16V | Parallel 2.5A, Series 1.25A | Dual | Dual | No | 20VA | Through Hole | PC Pin | 57.15mm L x 47.63mm W | 36.52mm | 2500Vrms | 0.8 lb (362.87 g) |
|
|
160F120PWR XFMR LAMINATED 4.4VA TH Hammond Manufacturing |
3,722 |
|
Datasheet |
160 | Bulk | Active | Laminated Core | 115V, 230V | Parallel 60V, Series 120V | Parallel 70mA, Series 35mA | Dual | Single, Multiple Taps | No | 4.4VA | Through Hole | PC Pin | 42.93mm L x 31.75mm W | 36.83mm | 2000Vrms | 0.32 lb (145.15 g) |
