Tantalum Capacitors
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Series | Packaging | Product Status | Capacitance | Tolerance | Voltage - Rated | Type | ESR (Equivalent Series Resistance) | Operating Temperature | Lifetime @ Temp. | Mounting Type | Size / Dimension | Height - Seated (Max) | Lead Spacing | Manufacturer Size Code | Ratings | Features | Failure Rate | Grade | Qualification |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
CWR26HK226MBGC\TRCAP TANT 22UF 20% 15V 2711 Vishay Sprague |
2,050 |
|
- |
CWR26 | Tape & Reel (TR) | Active | 22 µF | ±20% | 15 V | Conformal Coated | 275mOhm | -55°C ~ 125°C | - | Surface Mount | 0.265" L x 0.110" W (6.73mm x 2.79mm) | 0.125" (3.17mm) | - | G | - | High Reliability | B (0.1%) | Military | MIL-PRF-55365/13 |
|
|
CWR26HH226MBGC\TRCAP TANT 22UF 20% 15V 2711 Vishay Sprague |
4,977 |
|
- |
CWR26 | Tape & Reel (TR) | Active | 22 µF | ±20% | 15 V | Conformal Coated | 275mOhm | -55°C ~ 125°C | - | Surface Mount | 0.265" L x 0.110" W (6.73mm x 2.79mm) | 0.125" (3.17mm) | - | G | - | High Reliability | B (0.1%) | Military | MIL-PRF-55365/13 |
|
|
CWR26KK106MBGC\TRCAP TANT 10UF 20% 25V 2711 Vishay Sprague |
8,736 |
|
- |
CWR26 | Tape & Reel (TR) | Active | 10 µF | ±20% | 25 V | Conformal Coated | 350mOhm | -55°C ~ 125°C | - | Surface Mount | 0.265" L x 0.110" W (6.73mm x 2.79mm) | 0.125" (3.17mm) | - | G | - | High Reliability | B (0.1%) | Military | MIL-PRF-55365/13 |
|
CWR06FC105KB/PRCAP TANT 1UF 10% 10V 1005 Vishay Sprague |
2,752 |
|
- |
CWR06 | Tape & Reel (TR) | Active | 1 µF | ±10% | 10 V | Conformal Coated | 12Ohm | -55°C ~ 125°C | - | Surface Mount | 0.100" L x 0.050" W (2.54mm x 1.27mm) | 0.065" (1.65mm) | - | A | - | High Reliability | B (0.1%) | Military | MIL-PRF-55365/4 |
|
|
M39003/01-8268CAP TANT 1UF 20% 75V AXIAL Vishay Sprague |
9,551 |
|
- |
CSR13 | Bulk | Active | 1 µF | ±20% | 75 V | Hermetically Sealed | - | -55°C ~ 125°C | - | Through Hole | 0.185" Dia x 0.474" L (4.70mm x 12.04mm) | - | - | B | - | High Reliability | D (0.001%) | Military | MIL-PRF-39003/1 |
|
|
M39003/01-8268HCAP TANT 1UF 20% 75V AXIAL Vishay Sprague |
5,501 |
|
- |
CSR13 | Bulk | Active | 1 µF | ±20% | 75 V | Hermetically Sealed | - | -55°C ~ 125°C | - | Through Hole | 0.185" Dia x 0.474" L (4.70mm x 12.04mm) | - | - | B | - | High Reliability | D (0.001%) | Military | MIL-PRF-39003/1 |
|
|
M39003/01-8273CAP TANT 1.5UF 20% 75V AXIAL Vishay Sprague |
4,849 |
|
- |
CSR13 | Bulk | Active | 1.5 µF | ±20% | 75 V | Hermetically Sealed | - | -55°C ~ 125°C | - | Through Hole | 0.185" Dia x 0.474" L (4.70mm x 12.04mm) | - | - | B | - | High Reliability | D (0.001%) | Military | MIL-PRF-39003/1 |
|
|
M39003/01-8273HCAP TANT 1.5UF 20% 75V AXIAL Vishay Sprague |
5,746 |
|
- |
CSR13 | Bulk | Active | 1.5 µF | ±20% | 75 V | Hermetically Sealed | - | -55°C ~ 125°C | - | Through Hole | 0.185" Dia x 0.474" L (4.70mm x 12.04mm) | - | - | B | - | High Reliability | D (0.001%) | Military | MIL-PRF-39003/1 |
|
|
M39003/01-8278CAP TANT 2.2UF 20% 75V AXIAL Vishay Sprague |
4,184 |
|
- |
CSR13 | Bulk | Active | 2.2 µF | ±20% | 75 V | Hermetically Sealed | - | -55°C ~ 125°C | - | Through Hole | 0.185" Dia x 0.474" L (4.70mm x 12.04mm) | - | - | B | - | High Reliability | D (0.001%) | Military | MIL-PRF-39003/1 |
|
|
M39003/01-8278HCAP TANT 2.2UF 20% 75V AXIAL Vishay Sprague |
9,681 |
|
- |
CSR13 | Bulk | Active | 2.2 µF | ±20% | 75 V | Hermetically Sealed | - | -55°C ~ 125°C | - | Through Hole | 0.185" Dia x 0.474" L (4.70mm x 12.04mm) | - | - | B | - | High Reliability | D (0.001%) | Military | MIL-PRF-39003/1 |
