Limit Switches
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Series | Packaging | Product Status | Circuit | Switch Function | Current Rating (Amps) | Voltage Rating - AC | Voltage Rating - DC | Actuator Type | Mounting Type | Termination Style | Ingress Protection | Features | Operating Force | Release Force | Operating Position | Pretravel | Differential Travel | Overtravel | Operating Temperature |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
XCKN2110P20SWITCH LIMIT DPST 3A 240V |
4,608 |
|
Datasheet |
XC | Box | Active | DPST-NO/NC | On-Mom, Off-Mom | 3A (AC), 100mA (DC) | 240 V | 250 V | Round (Pin Plunger) | Chassis Mount | Screw Terminal | IP65 - Dust Tight, Water Resistant | - | - | - | - | - | - | - | -25°C ~ 70°C |
|
BZ-2RD244T1SWITCH SNAP ACTION SPDT 5A 125V |
2,075 |
|
Datasheet |
BZ | Bulk | Active | SPDT | On-Mom | 5A (AC), 500mA (DC) | 125 V | 125 V | Round (Pin Plunger) | Chassis Mount | Screw Terminal | - | Steel Plunger | 255 ~ 368gf | 113gf | 0.835" (21.2mm) | 0.015" (0.4mm) | 0.002" (0.05mm) | 0.062" (1.6mm) | -55°C ~ 204°C |
|
13SX1-TSWITCH SNAP ACTION SPDT 1A 125V |
2,974 |
|
Datasheet |
SX | Bulk | Active | SPDT | On-Mom | 1A (AC/DC) | 125 V | 30 V | Round (Pin Plunger) | Chassis Mount | Solder Turret | - | - | 99gf | 21gf | 0.320" (8.13mm) | 0.020" (0.5mm) | 0.001" (0.025mm) | 0.004" (0.1mm) | -55°C ~ 125°C |
|
|
BZ-2RQ9-A2SWITCH SNAP ACTION SPDT 15A 125V |
3,645 |
|
Datasheet |
BZ | Bulk | Obsolete | SPDT | On-Mom | 15A (AC), 500mA (DC) | 125 V | 125 V | Roller Plunger | Panel Mount | Screw Terminal | - | - | 255 ~ 368gf | 113gf | 1.953" (49.6mm) | 0.015" (0.4mm) | 0.002" (0.05mm) | 0.141" (3.6mm) | -55°C ~ 85°C |
|
|
BZ-7YQ1T1SWITCH SNAP ACTION SPDT 5A 250V |
4,305 |
|
Datasheet |
BZ | Bulk | Obsolete | SPDT | On-Mom | 5A (AC) | 250 V | - | Overtravel Plunger | Panel Mount | Screw Terminal | - | Steel Plunger | 850gf | 113gf | 0.859" (21.8mm) | 0.035" (0.9mm) | 0.007" (0.18mm) | 0.219" (5.6mm) | -55°C ~ 85°C |
|
|
A-20GDSWITCH SNAP ACTION SPDT 20A 125V |
1,590 |
|
Datasheet |
A | Bulk | Active | SPDT | On-Mom | 20A (AC), 6A (DC) | 125 V | 30 V | Round (Pin Plunger) | Chassis Mount | Solder Lug | IP00 | - | 400 ~ 625gf | 285gf | 1.030" (26.2mm) | 0.051" (1.3mm) | 0.008" (0.2mm) | 0.118" (3.0mm) | -25°C ~ 80°C |
|
|
Z-01HW25-BSWITCH SNAP ACT SPDT 0.1A 125V |
2,034 |
|
Datasheet |
Z | Bulk | Active | SPDT | On-Mom | 100mA (AC/DC) | 125 V | 30 V | Lever, Roller | Chassis Mount | Screw Terminal | IP00 | - | 100gf | 21gf | 1.622" (41.2mm) | - | 0.062" (1.6mm) | 0.158" (4.0mm) | -25°C ~ 80°C |
|
|
XCMH2110L1LS PL MINI MTL PLUGR NCNO SNAP 1 |
4,400 |
|
Datasheet |
XCMH | Bulk | Active | DPST-NO/NC | On-Off, Off-On | 750mA (AC), 100mA (DC) | 240 V | 250 V | Round (Pin Plunger) | Chassis Mount | Cable Leads | IP66/IP67 - Dust Tight, Water Resistant, Waterproof | - | - | - | - | - | - | - | -25°C ~ 70°C |
|
|
AZ40089SWITCH SNAP ACTION SPDT 5A 125V |
2,898 |
|
Datasheet |
AZ4 | Bulk | Active | SPDT | On-Mom | 5A (AC/DC) | 125 V | 30 V | Side Rotary, Adjustable Roller | Chassis Mount | Solder, Quick Connect - 0.110" (2.8mm) | IP64 - Dust Tight, Water Resistant | - | 205 ~ 450gf | 11 ~ 25gf | - | 15° | 3° | - | -20°C ~ 60°C |
|
|
12SM825SWITCH SNAP ACTION SPDT 1A 125V |
4,290 |
|
Datasheet |
SM | Bulk | Active | SPDT | On-Mom | 1A (AC/DC) | 125 V | 30 V | Round (Pin Plunger) | Chassis Mount | Solder Lug | - | - | 85gf | 28gf | 0.330" (8.4mm) | 0.020" (0.5mm) | 0.002" (0.05mm) | 0.003" (0.076mm) | -55°C ~ 125°C |
|
|
BZ-3AD-PC2SWITCH SNAP ACTION SPDT 15A 125V |
3,759 |
|
Datasheet |
BZ | Bulk | Obsolete | SPDT | On-Mom | 15A (AC), 1A (DC) | 125 V | 125 V | Round (Pin Plunger) | Chassis Mount | Screw Terminal | - | Steel Plunger | 454 ~ 737gf | 113gf | 0.835" (21.2mm) | 0.030" (0.8mm) | 0.005" (0.13mm) | 0.060" (1.5mm) | -55°C ~ 85°C |
|
|
Z-10FY-BSWITCH SNAP ACTION SPDT 10A 125V |
4,925 |
|
Datasheet |
Z | Bulk | Active | SPDT (DB/DM) | On-Mom | 10A (AC/DC) | 125 V | 30 V | Round (Pin Plunger) | Chassis Mount | Screw Terminal | IP00 | - | 455 ~ 740gf | 114gf | 0.625" (15.9mm) | 0.030" (0.8mm) | 0.004" (0.1mm) | 0.005" (0.13mm) | -25°C ~ 80°C |
|
|
V3-347SWITCH SNAP ACTION SPDT 1A 125V |
4,346 |
|
Datasheet |
V3 | Bulk | Active | SPDT | On-Mom | 1A (AC) | 125 V | - | Round (Pin Plunger) | Chassis Mount | Solder Lug | - | - | 227gf | 56.696gf | 0.578" (14.68mm) | 0.050" (1.27mm) | 0.016" (0.4mm) | 0.040" (1.02mm) | - |
|
BZ-2AW842444TSWITCH SNAP ACTION SPDT 15A 125V |
1,957 |
|
Datasheet |
BZ | Bulk | Obsolete | SPDT (DB/DM) | On-Mom | 15A (AC), 1A (DC) | 125 V | 125 V | Lever, Straight | Chassis Mount | Screw Terminal | - | - | 56gf | 3.500gf | 0.750" (19.1mm) | 0.328" (8.3mm) | 0.020" (0.5mm) | 0.219" (5.6mm) | -55°C ~ 85°C |
|
|
BZ-2RN702-NHSWITCH LARGE BASIC |
3,748 |
|
- |
* | Bulk | Obsolete | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
|
|
8604SWITCH AIR PRESSURE |
3,869 |
|
- |
- | Bulk | Obsolete | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
|
83169001SWITCH SNAP ACTION SPDT 10A 125V |
3,102 |
|
Datasheet |
83169 | Bulk | Active | SPDT | On-Mom | 10A (AC) | 125 V | - | Round (Pin Plunger) | Chassis Mount | Wire Leads | IP67 - Dust Tight, Waterproof | Cable Length 0.5m | 408gf | 102gf | 0.579" (14.7mm) | - | 0.014" (0.35mm) | 0.040" (1.0mm) | -20°C ~ 85°C |
|
83169002SWITCH SNAP ACTION SPDT 10A 125V |
2,903 |
|
Datasheet |
83169 | Bulk | Active | SPDT | On-Mom | 10A (AC) | 125 V | - | Round (Pin Plunger) | Chassis Mount | Wire Leads | IP67 - Dust Tight, Waterproof | Cable Length 0.5m | 408gf | 102gf | 0.579" (14.7mm) | - | 0.014" (0.35mm) | 0.040" (1.0mm) | -20°C ~ 85°C |
|
83123014SWITCH SNAP ACTION SPDT 5A 250V |
4,210 |
|
Datasheet |
83123 | Bulk | Active | SPDT | On-Mom | 5A (AC) | 250 V | - | Round (Pin Plunger) | Chassis Mount | Cable Leads | IP66 - Dust Tight, Water Resistant | - | 540gf | 153gf | 0.450" (11.4mm) | - | 0.008" (0.2mm) | 0.008" (0.2mm) | 0°C ~ 85°C |
|
83137055SWITCH SNAP ACTION SPDT 5A 125V |
3,342 |
|
Datasheet |
83137 | Bulk | Active | SPDT | On-Mom | 5A (AC) | 125 V | - | Side Rotary, Wire | Chassis Mount | Quick Connect - 0.187" (4.7mm) | - | - | 0.122gfm | 0.029gfm | - | - | 10° | 12° | -20°C ~ 125°C |
