Power Transformers
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Series | Packaging | Product Status | Type | Voltage - Primary | Voltage - Secondary (Full Load) | Current - Output (Max) | Primary Winding(s) | Secondary Winding(s) | Center Tap | Power - Max | Mounting Type | Termination Style | Size / Dimension | Height - Seated (Max) | Voltage - Isolation | Weight |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
1182F240PWR XFMR TOROIDAL 80VA CHAS MT Hammond Manufacturing |
4,315 |
|
Datasheet |
1182 | Box | Active | Toroidal | 117V, 234V | 240V | 333mA | Dual | Single | No | 80VA | Chassis Mount | Wire Leads | 88.90mm Dia | 38.10mm | 4000Vrms | 2.1 lbs (952.5 g) |
|
182P110PWR XFMR TOROIDAL 500VA CHAS MT Hammond Manufacturing |
1,127 |
|
Datasheet |
182 | Bulk | Active | Toroidal | 117V, 234V | Parallel 110V, Series 220V | Parallel 4.54A, Series 2.27A | Dual | Dual | No | 500VA | Chassis Mount | Wire Leads | - | 56.13mm | 4000Vrms | 8.5 lbs (3.9 kg) |
|
290CGPWR XFMR CHAS MT Hammond Manufacturing |
1,230 |
|
Datasheet |
290 | Bulk | Active | - | 120V, 240V | 338V, 6.3V, 43V | 450mA, 7A, 150mA | Dual | Triple | Yes | - | Chassis Mount | Wire Leads | 129.54mm L x 79.50mm W | 95.25mm | 2000Vrms | - |
|
275XPWR XFMR LAMINATED 167VA CHAS MT Hammond Manufacturing |
4,809 |
|
Datasheet |
275 | Bulk | Active | Laminated Core | 115V | 800V, 6.3V, 5V | 155mA, 5A, 3A | Single | Triple | Yes | 167VA | Chassis Mount | Wire Leads | 79.50mm L x 88.90mm W | 96.77mm | 2000Vrms | 5.8 lbs (2.6 kg) |
|
|
PWDM13203PWR XFMR CHAS MT Hammond Manufacturing |
3,031 |
|
Datasheet |
PWDAHL | Bulk | Active | - | 2450V | 1770V, 248V | 150mA, 50mA | Single | Dual | Yes | - | Chassis Mount | Wire Leads | 125.35mm L x 95.25mm W | 115.06mm | - | - |
|
|
PWDP13200PWR XFMR Hammond Manufacturing |
1,655 |
|
Datasheet |
PWDAHL | Case | Active | - | 120V, 240V | 1kV, 425V, 123V, 6.3V, 5V | 250mA, 11A, 3A | Dual | Four, Multiple Taps | Yes | - | Chassis Mount | Wire Leads | 133.35mm L x 133.35mm W | 111.13mm | - | - |
|
|
PWDP13054PWR XFMR LAMINATED CHAS MT Hammond Manufacturing |
3,872 |
|
Datasheet |
PWDAHL | Case | Active | Laminated Core | 120V, 240V | 1170V, 878V | - | Multiple, Single Tap | Single | No | - | Chassis Mount | Wire Leads | - | - | - | - |
|
PWDP13034PWR XFMR LAMINATED CHAS MT Hammond Manufacturing |
3,508 |
|
Datasheet |
PWDAHL | Case | Active | Laminated Core | 117V, 234V | 1171V, 860V | 700mA | Dual, Multiple Taps | Single | No | - | Chassis Mount | Wire Leads | 149.23mm L x 111.13mm W | 133.35mm | - | - |
|
160F56PWR XFMR LAMINATED 4.4VA TH Hammond Manufacturing |
3,186 |
|
Datasheet |
160 | Bulk | Active | Laminated Core | 115V, 230V | Parallel 28V, Series 56V | Parallel 160mA, Series 80mA | Dual | Single, Multiple Taps | No | 4.4VA | Through Hole | PC Pin | 42.93mm L x 31.75mm W | 36.83mm | 2000Vrms | 0.32 lb (145.15 g) |
|
|
6K270HF-BULKPWR XFMR Hammond Manufacturing |
2,720 |
|
- |
- | Bulk | Active | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
