Analog Devices Inc. ADAU7002ACBZ-R7
- Part No.:
- ADAU7002ACBZ-R7
- Manufacturer:
- Analog Devices Inc.
- Category:
- Audio Special Purpose
- Package:
- 8-UFBGA, WLCSP
- Datasheet:
-
ADAU7002ACBZ-R7.pdf
- Description:
- IC SAMPLE RATE CONVERTER 8WLCSP
- Quantity:
- Payment:
- Shipping:
Inventory:6,595
Please send an inquiry. Send us your inquiry, and we will respond immediately.
Overview
ADAU7002ACBZ-R7 is a low-power PDM-to-I²S/TDM converter from Analog Devices Inc., designed to interface digital MEMS microphones with DSPs and microcontrollers. It enables efficient digital audio signal conversion for modern embedded audio systems.
Key Specifications
- Function: PDM to I²S / TDM Converter
- Input: PDM Microphone Signal
- Output: I²S / TDM
- Supply Voltage: 1.8V
- Package: WLCSP
Pinout & Package
The ADAU7002ACBZ-R7 is packaged in a compact WLCSP format, suitable for high-density PCB designs. It includes PDM clock and data inputs, digital audio output pins, and power supply connections.
Key Features
- Low power consumption, making it suitable for battery-powered and portable audio devices such as wearables and IoT systems.
- Direct PDM-to-I²S conversion simplifies digital microphone integration, reducing system complexity and development time.
- Compact WLCSP package enables high-density PCB design, ideal for space-constrained applications.
- High audio fidelity with low latency ensures reliable performance in voice processing and audio signal applications.
- Compatible with a wide range of DSPs and microcontrollers, allowing flexible integration into embedded systems.
Applications
Smart Speaker Audio InterfaceUsed in smart speakers and voice assistants to convert MEMS microphone PDM signals into I²S audio data for DSP processing and voice recognition. |
MEMS Microphone InterfaceEnables direct integration of digital microphones without complex analog circuits, improving system efficiency and reducing design complexity. |
Wearable Audio DevicesIdeal for compact devices such as earbuds and smartwatches, where low power consumption and small form factor are critical. |
IoT Voice Control ModulesSupports voice command processing in IoT systems, providing stable digital audio signal conversion for smart home devices. |
Equivalent & Alternatives
Common alternatives include ADAU7118 for multi-channel audio applications. ADAU7002 is optimized for single-channel, low-power designs, while ADAU7118 supports more complex multi-channel systems.
Quality Assurance
- 100% original and genuine components sourced from reliable suppliers
- Strict quality inspection before shipment
- ESD-safe packaging to ensure product safety during transportation
- Full traceability of product batches
- Suitable for industrial and commercial applications
Manufacturer
Analog Devices Inc. is a global leader in high-performance analog, mixed-signal, and digital signal processing technologies, widely used in audio, industrial, automotive, and communication systems.
FAQ
What is ADAU7002 used for?
It converts PDM microphone signals into I²S or TDM digital audio formats for DSP processing.
Is ADAU7002 suitable for battery-powered devices?
Yes, its low power consumption makes it ideal for portable and wearable applications.
Does ADAU7002 support multi-channel audio?
No, it is designed for single-channel systems. For multi-channel designs, consider ADAU7118.
What type of microphones can be used with ADAU7002?
It is designed for digital MEMS microphones with PDM output.
