Pushbutton Switches
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Series | Packaging | Product Status | Mounting Type | Type | Circuit | Switch Function | Current Rating (Amps) | Voltage Rating - AC | Voltage Rating - DC | Actuator Type | Actuator Marking | Color - Actuator/Cap | Illumination Type, Color | Illumination Voltage (Nominal) | Termination Style | Ingress Protection | Features | Panel Cutout Dimensions | Operating Temperature |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
9221524525SWITCH PUSHBUTTON SPST-NO Dialight |
1,472 |
|
- |
922 | Bulk | Obsolete | Panel Mount, Rear | Standard, Illuminated | SPST-NO | Off-Mom | - | - | - | Round, Button | No Marking | - | - | - | Solder Lug | - | - | Circular - 9.58mm Dia | - |
|
5541231211SWITCH M/F BASIC PB Dialight |
4,192 |
|
Datasheet |
554 | Bulk | Obsolete | Panel Mount, Snap-In | Standard, Illuminated | DPDT | On-On | 7A (AC/DC) | 125 V | 30 V | Plunger for Cap | No Marking | - | - | - | Solder, Quick Connect - 0.110" (2.8mm) | - | - | Square - 19.25mm x 19.25mm | - |
|
|
5542122100SWITCH M/F BASIC PB Dialight |
3,293 |
|
- |
* | Bulk | Obsolete | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
|
|
91316031632525SWITCH PUSH DPST-NO 100MA 125V Dialight |
4,194 |
|
- |
913 | Bulk | Obsolete | Panel Mount, Rear | Standard, Illuminated | DPST-NO | Off-Mom | 100mA (AC/DC) | 125 V | 30 V | Round, Button | No Marking | - | LED, Green | - | Solder Lug | - | - | Circular - 9.58mm Dia | - |
|
|
5542121411SWITCH PUSHBUTTON SPDT 1A 125V Dialight |
2,605 |
|
Datasheet |
554 | Bulk | Obsolete | Panel Mount, Snap-In | Standard, Illuminated | SPDT | On-Mom | 1A (AC/DC) | 125 V | 30 V | Plunger for Cap | No Marking | - | - | - | Solder, Quick Connect - 0.110" (2.8mm) | - | - | Square - 22.35mm x 22.35mm | - |
|
|
513-0306-001SWITCH PB MOM 5/8" SQ DUAL Dialight |
4,650 |
|
Datasheet |
513 | Bulk | Obsolete | Panel Mount, Snap-In | Standard, Illuminated | DPST-NO/NC | On-Mom, Off-Mom | 3A (AC/DC) | 125 V | 30 V | Plunger for Cap | No Marking | - | - | - | Solder, Quick Connect - 0.110" (2.8mm) | - | - | Square - 19.25mm x 19.25mm | - |
|
|
554-1231IND SWITCH PB M/F Dialight |
1,622 |
|
Datasheet |
- | - | Obsolete | - | - | - | - | - | - | - | - | No Marking | - | - | - | - | - | - | - | - |
