Pulse Transformers
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Series | Packaging | Product Status | Transformer Type | Inductance | ET (Volt-Time) | Turns Ratio - Primary:Secondary | Mounting Type | Size / Dimension | Height - Seated (Max) | Operating Temperature | Grade | Qualification |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
HXU4009NLMDL SIN 2.5GPP 1:1 SMT TU Pulse Electronics |
2,450 |
|
- |
- | Tube | Active | - | - | - | - | - | - | - | - | - | - |
|
|
HX6188NLMDL SIN 1GPP 1:1 4PUPOE TU Pulse Electronics |
1,379 |
|
Datasheet |
- | Tube | Active | LAN 1000 Base-T | 350µH | - | 1:1 | Surface Mount | 0.715" L x 0.511" W (18.16mm x 12.98mm) | 0.400" (10.16mm) | -40°C ~ 85°C | - | - |
|
|
HX6188NLTMDL SIN 1GPP 1:1 4PUPOE TR Pulse Electronics |
3,404 |
|
Datasheet |
- | Tape & Reel (TR) | Active | LAN 1000 Base-T | 350µH | - | 1:1 | Surface Mount | 0.715" L x 0.511" W (18.16mm x 12.98mm) | 0.400" (10.16mm) | -40°C ~ 85°C | - | - |
|
|
GH5610RSY-3 LFMDL 1G DIP QUAD PORTS POE+ 30W Pulse Electronics |
3,883 |
|
Datasheet |
- | Tube | Active | LAN 1000 Base-T | 350µH | - | 1:1CT Transmitter, 1:1CT Receiver | Through Hole | 1.142" L x 1.043" W (29.00mm x 26.50mm) | 0.512" (13.00mm) | 0°C ~ 70°C | - | - |
|
PE-68026NL10BT FILTER MODULE WITH CMC Pulse Electronics |
4,202 |
|
Datasheet |
- | Tube | Obsolete | Isolation and Data Interface (Encapsulated) | - | - | 1:1 | Surface Mount | 0.920" L x 0.385" W (23.37mm x 9.78mm) | 0.230" (5.84mm) | 0°C ~ 70°C | - | - |
|
|
T2SD02LN6MDL 10G DUAL PORT N/A Pulse Electronics |
4,214 |
|
Datasheet |
- | Tape & Reel (TR) | Active | LAN 10 Base-T | 100µH | - | 1:1CT Transmitter, 1:1CT Receiver | Surface Mount | 1.291" L x 0.543" W (32.80mm x 13.80mm) | 0.287" (7.30mm) | -40°C ~ 90°C | - | - |
|
|
TX1281PULSE XFMR 1CT:1 2MH Pulse Electronics |
2,134 |
|
Datasheet |
- | Tray | Active | - | 2mH | - | 1CT:1 | Surface Mount | 0.220" L x 0.230" W (5.59mm x 5.84mm) | 0.200" (5.08mm) | -40°C ~ 85°C | - | - |
|
H5004TPULSE XFMR 1CT:1CT TX 1CT:1CT RX Pulse Electronics |
3,744 |
|
Datasheet |
- | Tape & Reel (TR) | Obsolete | LAN 10/100/1000 Base-T | - | - | 1CT:1CT Transmitter, 1CT:1CT Receiver | Surface Mount | 0.690" L x 0.480" W (17.53mm x 12.20mm) | 0.217" (5.51mm) | 0°C ~ 70°C | - | - |
|
|
T5038NLMODULE ISDN-S 1CT:2CT 30MH SMD Pulse Electronics |
1,318 |
|
Datasheet |
- | Tube | Active | Isolation and Data Interface (Encapsulated) | 30mH | - | 1CT:2CT, 1CT:2CT | Surface Mount | 1.170" L x 0.500" W (29.72mm x 12.70mm) | 0.326" (8.28mm) | 0°C ~ 70°C | - | - |
|
|
T5049NLXFMR ISDN S 1CT:1CT SMD RPB Pulse Electronics |
3,157 |
|
Datasheet |
- | Tube | Active | - | 30mH | - | 1:1CT | Surface Mount | 1.170" L x 0.500" W (29.72mm x 12.70mm) | 0.316" (8.03mm) | 0°C ~ 70°C | - | - |
