Through Hole Resistors
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Series | Packaging | Product Status | Resistance | Tolerance | Power (Watts) | Composition | Features | Temperature Coefficient | Operating Temperature | Supplier Device Package | Size / Dimension | Height - Seated (Max) | Number of Terminations | Failure Rate |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
45J25RERES 25 OHM 5% 5W AXIAL Ohmite |
152 |
|
Datasheet |
Ohmicone® 40 | Bulk | Active | 25 Ohms | ±5% | 5W | Wirewound | - | ±20ppm/°C | - | Axial | 0.343" Dia x 0.937" L (8.70mm x 23.80mm) | - | 2 | - |
|
20J2K5ERES 2.5K OHM 5% 10W AXIAL Ohmite |
421 |
|
Datasheet |
20 | Bulk | Active | 2.5 kOhms | ±5% | 10W | Wirewound | Flame Retardant Coating, Safety | ±30ppm/°C | - | Axial | 0.394" Dia x 1.858" L (10.00mm x 47.20mm) | - | 2 | - |
|
OY334KERES 330K OHM 10% 2W AXIAL Ohmite |
356 |
|
Datasheet |
OY | Bulk | Active | 330 kOhms | ±10% | 2W | Ceramic | Moisture Resistant, Pulse Withstanding | -1000/ -1600ppm/°C | -40°C ~ 220°C | Axial | 0.276" Dia x 0.748" L (7.00mm x 19.00mm) | - | 2 | - |
|
35J22RERES 22 OHM 5% 5W AXIAL Ohmite |
250 |
|
Datasheet |
High Energy Wirewound | Bulk | Active | 22 Ohms | ±5% | 5W | Wirewound | - | - | - | Axial | 0.343" Dia x 1.000" L (8.70mm x 25.40mm) | - | 2 | - |
|
23JR15ERES 0.15 OHM 5% 3W AXIAL Ohmite |
1,011 |
|
Datasheet |
20 | Bulk | Active | 150 mOhms | ±5% | 3W | Wirewound | Flame Retardant Coating, Safety | - | - | Axial | 0.220" Dia x 0.516" L (5.60mm x 13.10mm) | - | 2 | - |
|
40J1K0ERES 1K OHM 5% 10W AXIAL Ohmite |
816 |
|
Datasheet |
Ohmicone® 40 | Bulk | Active | 1 kOhms | ±5% | 10W | Wirewound | - | ±20ppm/°C | - | Axial | 0.406" Dia x 1.902" L (10.30mm x 48.30mm) | - | 2 | - |
|
41F400ERES 400 OHM 1% 1W AXIAL Ohmite |
248 |
|
Datasheet |
Ohmicone® 40 | Bulk | Active | 400 Ohms | ±1% | 1W | Wirewound | - | ±20ppm/°C | - | Axial | 0.126" Dia x 0.437" L (3.20mm x 11.10mm) | - | 2 | - |
|
OY561KERES 560 OHM 10% 2W AXIAL Ohmite |
854 |
|
Datasheet |
OY | Bulk | Active | 560 Ohms | ±10% | 2W | Ceramic | Moisture Resistant, Pulse Withstanding | -1000/ -1600ppm/°C | -40°C ~ 220°C | Axial | 0.276" Dia x 0.748" L (7.00mm x 19.00mm) | - | 2 | - |
|
25J3K3ERES 3.3K OHM 5% 5W AXIAL Ohmite |
243 |
|
Datasheet |
20 | Bulk | Active | 3.3 kOhms | ±5% | 5W | Wirewound | Flame Retardant Coating, Safety | ±30ppm/°C | - | Axial | 0.276" Dia x 1.016" L (7.00mm x 25.80mm) | - | 2 | - |
|
|
41F250ERES 250 OHM 1% 1W AXIAL Ohmite |
253 |
|
Datasheet |
Ohmicone® 40 | Bulk | Active | 250 Ohms | ±1% | 1W | Wirewound | - | ±20ppm/°C | - | Axial | 0.126" Dia x 0.437" L (3.20mm x 11.10mm) | - | 2 | - |
