Pulse Transformers
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Series | Packaging | Product Status | Transformer Type | Inductance | ET (Volt-Time) | Turns Ratio - Primary:Secondary | Mounting Type | Size / Dimension | Height - Seated (Max) | Operating Temperature | Grade | Qualification |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
PA3493NLPULSE XFMR 1.25:1 656UH Pulse Electronics |
1,380 |
|
Datasheet |
- | Tube | Active | - | 656µH | 23VµS | 1.25:1 | Surface Mount | 0.430" L x 0.380" W (10.92mm x 9.65mm) | 0.105" (2.67mm) | -40°C ~ 130°C | - | - |
|
PA0264NLTPULSE XFMR 1:1:1 1.14MH Pulse Electronics |
4,944 |
|
Datasheet |
- | Tape & Reel (TR) | Active | - | 1.14mH | 17.2VµS | 1:1:1 | Surface Mount | 0.340" L x 0.265" W (8.64mm x 6.73mm) | 0.140" (3.56mm) | -40°C ~ 130°C | - | - |
|
PA0185NLPULSE XFMR 1:1 980UH Pulse Electronics |
1,158 |
|
Datasheet |
- | Tube | Active | - | 980µH | 17.2VµS | 1:1 | Surface Mount | 0.340" L x 0.460" W (8.64mm x 11.68mm) | 0.160" (4.06mm) | -40°C ~ 130°C | - | - |
|
|
PA0185NLTPULSE XFMR 1:1 980UH Pulse Electronics |
1,243 |
|
Datasheet |
- | Tape & Reel (TR) | Active | - | 980µH | 17.2VµS | 1:1 | Surface Mount | 0.340" L x 0.460" W (8.64mm x 11.68mm) | 0.160" (4.06mm) | -40°C ~ 130°C | - | - |
|
PE-65723NLTRANSFORMER 2000VRMS 75UH SMD Pulse Electronics |
551 |
|
Datasheet |
- | Tube | Active | Isolation and Data Interface (Encapsulated) | 75µH | 1.8VµS | 1:1 | Surface Mount | 0.500" L x 0.285" W (12.70mm x 7.24mm) | 0.210" (5.33mm) | 0°C ~ 70°C | - | - |
|
P0544NLPULSE XFMR 1:1:1 3.3MH Pulse Electronics |
1,452 |
|
Datasheet |
- | Tube | Active | - | 3.3mH | 45.1VµS | 1:1:1 | Surface Mount | 0.355" L x 0.340" W (9.02mm x 8.64mm) | 0.300" (7.62mm) | -40°C ~ 130°C | - | - |
|
PA0184NLPULSE XFMR 1:1 1.2MH Pulse Electronics |
944 |
|
Datasheet |
- | Tube | Active | - | 1.2mH | 27.2VµS | 1:1 | Surface Mount | 0.355" L x 0.340" W (9.02mm x 8.64mm) | 0.300" (7.62mm) | -40°C ~ 130°C | - | - |
|
PM2185.011NLTXFMR GATE-DR 1CT:1CT SM NPB Pulse Electronics |
309 |
|
Datasheet |
PM2185.XXXNL | Tape & Reel (TR) | Active | Isolation and Data Interface (Encapsulated) | 538µH | 24VµS | 1CT:1CT | Surface Mount | 0.362" L x 0.323" W (9.20mm x 8.20mm) | 0.299" (7.60mm) | -40°C ~ 125°C | - | - |
|
PH9572.111ANLTGDT, FUNCTIONAL, EP7, SMT Pulse Electronics |
4,324 |
|
Datasheet |
- | Tape & Reel (TR) | Active | Gate Drive | 4mH | 84.7VµS | 1:1:1 | Surface Mount | 0.402" L x 0.295" W (10.20mm x 7.50mm) | 0.433" (11.00mm) | -40°C ~ 125°C | - | - |
|
PA2467NLTPULSE XFMR 37UH Pulse Electronics |
1,170 |
|
Datasheet |
- | Tape & Reel (TR) | Active | - | 37µH | - | - | Surface Mount | 0.551" L x 0.516" W (14.00mm x 13.11mm) | 0.485" (12.32mm) | -40°C ~ 130°C | - | - |
